Written 8 December 2022

Published on 10 December, after vulnerabilites were closed.

Hacking your water heater for fun and profit

Ok, no profit.

I love home automation and have my airbnb fully automated. In mid November 2022, my water leak sensor detected a leak near my hot water heater and automatically shut off the water to the house. A 3 hour drive later, I discovered my old water heater had failed pretty spectacularly.

After some research, I decided to buy a $WaterHeaterCompany 80 gallon hybrid water heater (traditional heating elements + heat pump) to replace it. I had already used a GE 220v/40A ZWave smart switch to turn my old water heater on/off based on the Airbnb calendar, but this $WaterHeaterCompany unit has wifi and can be put into ‘vacation mode’, which is better because it keeps the water at 65ºF/18ºC, out of freezing danger in the winter months.

I took over a non-maintained Hubitat $WaterHeaterCompany integration and began exploring their API. Most of the hard work was done by others prior, I just wanted to fully understand how it worked.

$WaterHeaterCompany uses the ClearBlade platform and have both an HTTP and an MQTT API. I was able to use CharlesProxy on my iPhone to man-in-the-middle the HTTP API to understand how to get a bearer token (a JWT) as well as capture the webhooks the phone sends when you enter/leave a geofence to put your devices in away mode.

ClearBlade documentation told me about MQTT user and device topics. With my bearer token, I was able to publish to the topic user/{userId}/desired (desired state - where requests are made) and subscribe to the topic user/{userId}/reported (reported state - where acknowledgements happen). I was already familiar with this concept as I have extensive experience with AWS IoT Core, which uses similar nomenclature.

I tried subscribing to # (MQTT wildcard)…and immediately got a flood of data that included:

  • Emails any time a user logged in or out of the app
  • All device information including temperature sensor statuses, owner zip code, and mode (vacation mode!)

I immediately contacted anyone at $WaterHeaterCompany that sounded IT/Platform/Security related on LinkedIn - as well as their security compliance email - and told them I need to discuss a serious vulnerability in their API - and that I had access to a list of customers that logged into their app.

I received an email from their compliance department that they would look into it and get back to me.

In the mean time, I wrote a little service that opened up a subscription to # and filtered on my device information, which is published to the topic device/{mac_address}/{serial_number}/{model_id}/reported (I did not have permissions to subscribe directly to my device topic).

I actually hit my Comcast data cap because the MQTT stream was ~130GB/day worth of data.

I was able to get lots of neat information: Compressor run time, kWh consumed, tank temperature.. There were a dozen or more parameters:

      "FAN_CTRL": 0,
      "COMP_RLY": 0,
      "EXACTUAL": 100,
      "HRSLOFAN": 35.308345,
      "HRS_COMP": 97.127822,
      "WHTRENAB": 1,
      "WHTRSETP": 120,
      "HOTWATER": 60,
      "HRSHIFAN": 61.998172,
      "PRODDESC": "Heat Pump Water Heater          ",
      "PRODSERN": "XXXXXXXXXX                      ",
      "UNITTYPE": 4,
      "PRODMODN": "XE80T10H+45U0                   ",
      "SW_VERSN": "WH-HPW5-H6-01-04",
      "SERIAL_N": [
        "XXXXX"
      ],
      "UPELSIZE": 4.5,
      "LOELSIZE": 4.5,
      "LSDETECT": 0,
      "HEATCTRL": 0,
      "SHUTOFFV": 0,
      "SHUTOVER": 0,
      "ANODEA2D": 42405,
      "ANODESTS": 2,
      "SHUTOPEN": 0,
      "SHUTCLOS": 0,
      "HRSUPHTR": 2.938611,
      "HRSLOHTR": 0.002222,

Many of the key/values I didn’t understand, so I did what I usually do: Search github!

Doing that, I found something even more alarming: A public repository that appeared to be all of their Python QA test automation scripts. This included READMEs, test accounts, and the password for admin@$WaterHeaterCompany.com.

This can’t be a user in their production environment, can it?

Yes, it can. I successfully logged into their app.

A week goes by, and I notice that I can no longer subscribe to #. Ok, someone investigated after I sent the LinkedIn messages and closed that hole.

So I went back to ClearBlade documentation, and found they have another “trigger” topic that gets published to for “user:login”, “device:create”, etc. The payloads contained email addresses and device serial numbers.

As it turns out, any user still has access to subscribe to $trigger/# and receive all of that information.

Almost 2 weeks had passed since I received the “we’ll look into it” reply, so I replied again saying that I’d really like to talk, and this time I attached a list of emails who had launched the app in the past 10 minutes.

That got their attention, and we scheduled a call. Within hours, I lost access to $trigger/#.

In the meantime, I grabbed a bearer token for the admin@$WaterHeaterCompany account to see if it had any additional MQTT permissions.

Oh yeah. It did.

With these credentials, I could publish or subscribe to any topic. That means I could publish payloads to /desired, changing the settings on anyone’s water heater or thermostat. I really should have just renamed everyone’s devices to pwned.

Today, I had a call with $WaterHeaterCompany, and talked about how I discovered what I did and gave them several recommendations. $WaterHeaterCompany does not offer a bug bounty, and my only request was for them to grant a user access to their own device’s /reported topic, for nerdy data-gatherers like myself. We’ll see if that happens.

Obviously, that admin account password was changed by $WaterHeaterCompany shortly after I got off the call with them. JWTs have been revoked.

The public repo with the admin password has been taken down.

For now, however, my MQTT connection capturing my water heater stream is still open.

I wonder how much of the $WaterHeaterCompany API github copilot will autocomplete :).
